常州は勝利パックCO.、株式会社を結合した
| 起源の場所: | 中国 |
|---|---|
| ブランド名: | unitedwin |
| モデル番号: | PETFA-70 |
| 最小注文数量: | 1セット |
| 価格: | 7000 - 14000USD 1 set |
| パッケージの詳細: | 木製のケース |
| 受渡し時間: | 30日 |
| 製品名: | テープ放出ライン | 電圧: | 220V |
|---|---|---|---|
| フレームの次元: | 1600mm*1350mm*2260mm | 重さ: | 890KG |
| 最大巻き直径: | 800mm | 巻き戻し範囲: | 9mm-33mm |
| 紙のチューブの長さ: | ≤200mm | 最大電力: | 2.0 kW |
| ハイライト: | 1.6M PET strap extrusion line,3000W electric motor winding machine,high efficiency coil winding machine |
||
The 1.6M PET Strap Extrusion Line with 3000W Electric Motor is an energy-efficient, high-performance machine designed for producing PET strapping bands with excellent tensile strength and stability. This extrusion line offers reliable output, advanced automation, and superior winding accuracy, ideal for industrial-scale PET strap manufacturing.
This PET strap extrusion line integrates material drying, extrusion, filtering, stretching, embossing, cooling, and automatic winding into a continuous automated process. The system features a precision screw design that ensures uniform melting and stable extrusion of PET granules, resulting in consistent strap dimensions and smooth surface finish.
The 1.6M working width supports multi-line production, allowing the manufacture of multiple PET straps simultaneously, significantly improving production efficiency and throughput.
A 3000W high-efficiency electric motor powers the coil winding section, ensuring stable tension control and perfect roll formation without deformation. The PLC-controlled system automatically synchronizes speed, temperature, and winding torque, providing precise and reliable performance under continuous operation.
| Appearance and dimensions | 1650mm*1400mm*2200mm | Maximum winding diameter | 800MM |
|---|---|---|---|
| Machine weight | About 890KG | Rewind-up range | 8MM-32MM |
| Input power | 220V | Length of paper tube | ≤200MM |
| Maximum power | 2.0KW | Equipment model | PETQZD-70 |
| Maximum operating pressure of the system | 0.8MPa | Minimum operating pressure of the system | 0.6MPa |
Q: How long is the warranty period for your machine?
A: All our machines have a 12 - month guarantee for mechanical parts and 6 months for electrical parts, starting from the finished installation.
Q: How many days will you finish installing?
A: We will finish installation and training within 15 days.
Q: Do you control the items quality?
A: Yes, we control the quality one by one before shipping.
Q: Can I get some tape samples for testing before placing an order?
A: Yes. We can provide you with some free samples for your reference.
Q: What is the payment method?
A: 30% T/T as a deposit before production, 70% T/T after a copy of B/L.
